WFY100 Jaw crusher
  • Summary
  • Feature
  • Parameter
  • Video
  • Contact
  • The instrument is suitable for medium-hard, hard, brittle and hard ductile materials with fast coarse crushing and pre-crushing process in the lad. The machine has many jaw types with different materials. With excellent equipment performance and safety performance, it will be an ideal choice for sample treatment in your laboratory or enterprise production.

  • 1.Excellent crushing performance, continuously grinding
    2.Dust proof interface, easy cleaning and crushing cavity
    3.Jaw plate gap can be adjusted continuously
    4.Anti splash feed hopper and quickly fixed
    5.Motor is with fast braking performance and safety protection switch
    6.Non polluting crushing of various materials. Oxide ceramics, slag, coke, glass, basalt, ore, quartz, feldspar, ceramics and other materials of grinding

  • WFY60 technical parameters
    1.Max sample size: <60mm
    2.Final discharging particles: Minimum 0.2mm, continuously adjustable
    3.Jaw plate kit material: Stainless steel and manganese steel
    4.Jaw plate size: 237mm*60mm
    5.Jaw plate gap width: 0.2-15mm, adjustable
    6.Power: 220V AC/50Hz,0.75KW
    7.Dimension(L*H*W): 640mm*660mm*740mm
    8.Net weight: 110Kg

    WFY100 technical parameters
    1.Max sample size: <100mm
    2.Final discharging particles: Minimum 0.2mm, continuously adjustable
    3.Jaw plate kit material: Stainless steel and manganese steel
    4.Jaw plate size: 237mm*100mm
    5.Jaw plate gap width: 0.2-15mm, adjustable
    6.Power: 3 phase 380V AC,1.5KW
    7.Dimension(L*H*W): 424mm*942mm*800mm
    8.Net weight: 215Kg
